Metallic

General Details

Tie Rod and Control Rod

AvetchTyee manufactures a large range of Tie Rods, Push-Pull Rods, and Control Rods assemblies in Aluminum, Titanium, or Stainless Steel. With one of our leading market specialties, rotary swaging for tie and control rod tubes has the capability of sizes up to 4.5-inch diameter and over 12 feet in length. Swaged tubes is by far the most cost to weight effective while exhibiting excellent fatigue strength.

Struts

Structural struts are manufactured by using aluminium, titanium or stainless steel and are swaged in a cold forming process. This style of rod produces a highly fatigue resistant strut and comparatively light weight for it’s strength. The Ends can be flange or plain bushings as needed to attach to the mating surface. This type of strut is used for structural support, landing gears, engine mounting, HTP and VTP support structures.

Swaged Rods

AvtechTyee produces numerous rod designs that rely on a process called Rotary Swaging.  Rotary Swaging is a mechanical form of forging that applies the power and speed of rotary machines to the blacksmiths manual method.  In manual swaging, the swage (or die) is placed in the hardy hole of the anvil, and the blacksmith holds the hafted upper die in one hand while he slowly turns the work piece with the other.  A helper meanwhile strikes the upper die with a sledge.  In a rotary swager, the die and hammer blocks are held in a cross-slot in the end of the rotating spindle, and are thrown open by centrifugal force.  The outward travel is limited by opposing pairs of rollers that are caged like in a roller bearing.  The rollers turn freely against the outer race that is pressed into the frame of the machine.  As the hammer blocks pass under the rollers, they cause the dies to strike the work piece.  Rotary swaging increases the mechanical properties of the material being worked, and allows for high rates of production to close tolerances.  AvtechTyee maintains in-house capability to develop dies for custom angles and shapes in forming.

Swaged Materials

Swaging metals requires some amount of ductility.  Materials having less than 10% elongation are less useful.  Many high strength alloys that otherwise would have desirable characteristics in the finished part may not be easily swaged.  Swaging produces an increase in wall thickness, but results in progressive loss of cross section due to the elongation of the material.

2024 aluminum tubing is the most common structural aircraft material.  In the “0” condition, it is ductile and swageable.  Although is requires heat treatment, straightening, and a protective finish, it remains a readily manufactured material.  6061 aluminum alloy can also be swaged.  High strength steel tubing that is ductile can also be swaged.  Processing is usually less for corrosion resistant materials.  AISI 321, 347, 15-5, 17-4 stainless and carbon steels in the 4130, 4340 families have been used as swaged rod body materials at AvtechTyee.  Many other alloys can be swaged, including titanium alloys.  AvtechTyee maintains a wide library of material process models to design swaged tube design efficiently with tight tolerances and performance.

Metallic Rod Design Considerations

Metallic rods for aircraft control or structural support typically have design requirements for fatigue and static strength, with resistance to corrosion at a minimum weight.  Rod assembly designs must meet calculated ultimate loads, both in compression and tension, but often the critical design parameter is fatigue loading.  A design that optimizes fatigue strength of the original material through careful manufacturing processing is key.

Corrosion and stress can seriously shorten the life of a mechanical assembly.  Most tubes are exposed to a corrosion inducing environment.  Tubes exposed to the low temperatures and low air pressures of altitude cause air to evacuate.  Then, returning to warmer humid air at ground level, the tube refills with moist air that may condense into liquid.  The most corrosive location on aircraft applications is adjacent to the landing gear, where sprays from the runway and ground equipment contact exposed assemblies.  Moisture is basic to galvanic action, and conductive to corrosion between any steel and aluminum.  Good design will preclude the contact of dissimilar materials.

Assembly weight and size is also a key consideration.  Fittings should be only of sufficient diameter to support required loads.  Movable or articulated rods, are often in close contiguity with other structures, and need to avoid interference with any mating surfaces or parts.  Tube thickness, end fitting type, and materials all play key roles in space and weight of control or structural rods.

Integrally Formed Clevises

Metallic assemblies can reduce weight and complexity in some applications through the use of a integrally formed clevis.  This offers a good solution for redundancy paths on control systems, and saves weight.  A bushing or other mount can be fitted into the “ears”, with any “clocking” arraignment possible between ends.

Snubbers

Historically, linear motion arresting devices, known as Snubbers, have used a closed hydraulic system to achieve the required braking action.  However, some applications, especially in extreme aerospace environments, cannot use hydraulic oils.  This is where AvtechTyee provide a novel design solution with purely mechanical braking action in proportion to the load applied.  These designs are lighter weight and less complex than most hydraulic solutions, and meet extreme temperature, humidity, altitude, and flammability requirements.

The mechanical snubbers are designed to operate while extending or compressing, and may be used as a support at the end of the stroke.  Parts currently designed support loads as low as 75 pounds, all the way up to 1 inch diameter snubbers supporting 1000 pounds.  Snubbers may also be designed to control rotary motion in a similar controlled manner.

Snubber Design Considerations

To design a custom snubber, AvtechTyee requires the following information:

Closed Length:
Minimum Travel:
Operating Load Range:
Static Loads:
Time Envelope:
Maximum Working Diameter:
Method of Operation:
Connection Requirements.
Tube bodies can be metallic or composite, with a variety of threaded or formed end fitting inserts.

Products Detail

Products Detail

Item NumberDescriptionTSO
1000-1TENSION TIE
1042-13GALLEY TIE ASSY
1042-19ROD ASSEMBLY
1042-2ROD ASSEMBLY
1042-21-PMAGALLEY TIE ASSY
1042-21-TYGALLEY TIE ASSY
1042-23Rod Assy
1042-23-TYROD ASSY
1042-25GALLEY TIE ASSY
1042-27-TYROD ASSY
1042-29ROD ASSY
1042-31ROD ASSY
1042-33ROD ASSY
1042-35ROD ASSY
1042-37ROD ASSY
1042-39ROD ASSY
1042-41ROD ASSY
1042-5ROD ASSEMBLY
1042-6ROD ASSEMBLY
1042-9GALLEY TIE ASSY
1051-1ROD ASSEMBLY
1055-1ROD ASSEMBLY
1055-3ROD ASSEMBLY
1064-1LOCK ASSEMBLY
1070-17GALLEY TIE ASSEMBLY
1070-43ROD ASSY
1070-45RROD ASSY
107C1553-1ROD ASSY
107C1553-6ROD ASSY
107C2551-12ROD ASSY
107C2551-13ROD ASSY
107C2551-2ROD ASSY
107C2553-1TUBE SUB ASSY
107C2553-10TUBE ASSY
107C2553-3TUBE ASSY
107C2553-6TUBE ASSY
107C2553-7TUBE ASSY
107C2553-8TUBE SUB ASSY
107C2553-9TUBE SUBASSY
107C2554-10TUBE ASSY
107C2554-12TUBE SUB ASSY
107C2554-14TUBE SUB ASSY
107C2554-17TUBE SUBASSY
107C2554-18CONNECTING LINK
107C2554-19TUBE SUB ASSY
107C2554-20TUBE SUB ASSY
107C2554-5TUBE SUB ASSY
107C2554-7ROD SUB ASSY
107C2554-9TUBE ASSY
111T7214-001IGWFROD ASSY
111T7214-1ROD ASSY
112A7110-1ROD ASSY
112A7110-2ROD ASSY
112T7056-1ROD ASSY
112T7056-2ROD ASSY
113N1442-3TUBE ASSY
113N1442-5TUBE ASSY
113N1444-9TUBE ASSY
113N1820-1ROD ASSY
113N2888-13ROD ASSY
113N2888-14ROD ASSY
113N3022-1ROD ASSY
113N3022-2ROD ASSY
113N3022-3ROD ASSY
113N3022-4ROD ASSY
113T1732-1ROD ASSY
113T1910-62ROD ASSY
113T1910-67ROD ASSY
113T1910-68ROD ASSY
113T1910-69ROD ASSY
113T1910-72ROD ASSY
113T1910-73ROD ASSY
113T8315-3LINK ASSY
113W1452-5PUSH ROD ASSY
113W2126-11PUSH ROD ASSY
113W2126-15PUSHROD ASSY
113W2126-7ROD ASSY
113W6910-1ROD ASSY
113W6910-2ROD ASSY
113W8347-5ROD ASSY
113W8347-5-CSROD ASSY
113W8347-6ROD ASSY
113W9105-1ROD ASSY
113W9205-1ROD ASSY
113W9208-1ROD ASSY
114C1010-4CONNECTING LINK
114C1010-5CONNECTING LINK
114C1013-4CONNECTING LINK
114C1013-7CONNECTING LINK
114C3340-18CONNECTING LINK
114T6422-1ROD ASSY
114T6423-1LINK ASSY
114T6426-1ROD ASSY
114U0041-11TUBE ASSY
115-1145-1-CSHINGE ASSY
115-1310-1SUPPORT ASSY
115-1310-2SUPPORT ASSY
115-1319-1-CSEXTENSION ASSY
115-1319-3-CSEXTENSION ASSY
115-1320-1-CSEXTENSION ASSY
115-1320-1-CSMEXTENSION ASSY
115-1320-1-CSM1EXTENSION ASSY
115-1333-1-CSZEE ASSEMBLY
115-1333-2-CSZEE ASSEMBLY
115-1336-1-CSZEE ASSEMBLY
115-1344-1-CSSUPPORT ASSY
115-1344-2-CSSUPPORT ASSY
115-1360-1-CSLATCH ASSY
115-1364-1-CSBODY ASSY LATCH
115-1370-1PUSHROD ASSY
115-1370-1-CSPUSHROD ASSY
115-1370-1-CSMPUSHROD ASSY
115-1370-3ROCKER ASSY
115-1370-3-CSROCKER ASSY
115-1370-4ROCKER ASSY
115-1370-4-CSROCKER ASSY
115-1510-1-CSDRIVER ASSY
115-1510-1-CSMDRIVER ASSY
115-1510-11-CSDRIVER
115-1510-12-CSDRIVER
115-1510-2-CSDRIVER ASSY
115-1510-2-CSMDRIVER ASSY
115-1515-1-CSIDLER ASSY
115-1515-1-CSMIDLER ASSY
115-1520-1-CSCARRIAGE LINK ASSY
1159AC50063-1ROD ASSY
1159AC50063-11ROD ASSY
1159AC50063-25ROD ASSY
1159AC50063-29ROD ASSY
1159AC50063-3ROD ASSY
1159AC50063-35ROD ASSY
1159AC50063-5ROD ASSY
1159AC50063-7ROD ASSY
1159C20260-9PUSHROD ASSY
1159C20260-9-CSROD ASSY
1159C20458-1ROD ASSY
1159C20458-3ROD ASSY
1159HM20147-3FITTING ASSY
1159HM20181-5TUBE
115A2950-1TURNBUCKLE ASSY
115A2950-11TURNBUCKLE ASSY
115A2950-13TURNBUCKLE ASSY
115A2950-15TURNBUCKLE ASSY
115A2950-17TURNBUCKLE ASSY
115A2950-19TURNBUCKLE ASSY
115A2950-23TURNBUCKLE ASSY
115A2950-3TURNBUCKLE ASSY
115A2950-31TURNBUCKLE ASSY
115A2950-33TURNBUCKLE ASSY
115A2950-34TURNBUCKLE ASSY
115A2950-35TURNBUCKLE ASSY
115A2950-36TURNBUCKLE ASSY
115A2950-37TURNBUCKLE ASSY
115A2950-38TURNBUCKLE ASSY
115A2950-39TURNBUCKLE ASSY
115A2950-40TURNBUCKLE ASSY
115A2950-41TURNBUCKLE ASSY
115A2950-47TURNBUCKLE ASSY
115A2950-64TURNBUCKLE ASSY
115A2950-7TURNBUCKLE ASSY
115A2950-9TURNBUCKLE ASSY
115U4124-1TIE ROD ASSY
115W2190-43ROD ASSY
115W4770-1TUBE ASSY
1170-1GALLEY TIE ASSY
1170-11RGALLEY TIE ASSY
1180-101ROD ASSY
12025-1PUSH ROD ASSY
12035-1PUSH ROD ASSY
12101-1ROD ASSY
123AMM12131-1PUSHROD ASSY
1254-1ROD END ASSY
1254-14ROD END ASSY
1254-15ROD END ASSY
1254-18LRod End Assy
1254-19ROD END ASSY
1254-1LROD END ASSY
1254-20ROD END ASSY
1254-3ROD END ASSY
1254-3LRod End Assy
1254-7ROD END ASSY
1258-1SNUBBER ASSEMBLY
1270-5ROD ASSEMBLY
1271-3TUBE ASSY
1271-51ROD ASSY
1271-69TUBE ASSY
1271-7TUBE ASSY
1271-7-CSTUBE ASSY
1274-1Snubber Assy
1274-20SNUBBER ASSY
127459-CSPISTON ROD
1280-1Rod Assy
1280-13ROD ASSY
1280-15Rod Assy
1280-17Rod Assy
1280-19Rod Assy
1280-21ROD ASSY
1280-25ROD ASSY
1280-27Rod Assy
1280-29ROD ASSEMBLY
1280-31Rod Assy
1280-33Rod Assy
1280-37Rod Assy
1280-41Rod Assy
1280-43Rod Assy
1280-45Rod Assy
1280-49Rod Assy
1280-5Rod Assy
1280-7Rod Assy
1280-9ROD ASSY
1281-1TENSION TIE ASSY
1289-1ROD ASSY
1290-1ROD END ASSY
1290-11ROD END ASSY
1290-13ROD END
1290-3ROD END ASSY
1290-9ROD END
1293-1Rod Assy
1293-103Rod Assy
1293-105Rod Assy
1293-109ROD ASSY
1293-11Rod Assy
1293-111ROD ASSY
1293-113ROD ASSY
1293-13Rod Assy
1293-15Rod Assy
1293-17Rod Assy
1293-19Rod Assy
1293-21Rod Assy
1293-23Rod Assy
1293-25Rod Assy
1293-27Rod Assy
1293-29ROD ASSY
1293-3Rod Assy
1293-31Rod Assy
1293-33Rod Assy
1293-35Rod Assy
1293-39Rod Assy
1293-41Rod Assy
1293-43Rod Assy
1293-43-PMAGALLEY TIE ASSY
1293-45ROD ASY
1293-47Rod Assy
1293-49TUBE ASSEMBLY
1293-5Rod Assy
1293-51Rod Assy
1293-55Rod Assy
1293-57Rod Assy
1293-59Rod Assy
1293-61Rod Assy
1293-63Rod Assy
1293-65Rod Assy
1293-69Rod Assy
1293-7ROD ASSY.
1293-71Rod Assy
1293-77Rod Assy
1293-79Rod Assy
1293-81Rod Assy
1293-83Rod Assy
1293-85Rod Assy
1293-87Rod Assy
1293-89Rod Assy
1293-9ROD ASSY.
1293-91Rod Assy
1293-93Rod Assy
1293-95Rod Assy
1293-97Rod Assy
1298-3GALLEY TIE
1308-1Snubber Assy
1317-1Rod Assy
1317-11Rod Assy
1317-15Rod Assy
1317-15-PMAGALLEY TIE ASSY
1317-3ROD ASSY
1317-5ROD ASSY
1317-7ROD ASSY
1317-9Rod Assy
1323-27ROD ASSEMBLY
1324-1ROD END ASSY
1324-3ROD END ASSY
13264581ROD ASSY
1328-1ROD ASSY
1328-1-GROD ASSY
1328-2ROD ASSY
1328-2-GROD ASSY
1328-2-MROD ASSY WITH NSN
1328-3ROD ASSY
1328-3-GROD ASSY
1328-4ROD ASSY
132Z4246-1LINK ASSY
132Z4246-3LINK ASSY
132Z7501-1BC LINK ASSY
132Z7501-3BC LINK ASSY
132Z7503-1LINK ASSY
132Z7503-3LINK ASSY
1330-1ROD ASSY
1333-3TURNBUCKLE ASSY
1334-1ROD ASSY
1334-1-MMROD ASSY
1334-2ROD ASSY
1334-2-MROD ASSY
1334-2-M1ROD ASSY
1334-3ROD ASSY
1334-3-MROD ASSY
1334-3-MMROD ASSY
1334-4ROD ASSY
1334-4-MMROD ASSY
1334-5ROD ASSY
1334-5-MROD ASSY
1334-7ROD ASSY
1334-7-GROD ASSY
1334-7-MROD ASSY
1334-7-MMROD ASSY INCORPORATING SPCO 01
1334-9ROD ASSY
1344-3ROD ASSY
1344-4ROD ASSY
1344-5ROD ASSY
1344-6ROD ASSY
146A9816-1TIE ROD ASSEMBLY
146A9816-2TIE ROD ASSEMBLY
146A9816-3TIE ROD ASSEMBLY
146A9816-4TIE ROD ASSEMBLY
1476-1ROD ASSY - GALLEY TIE
1488-9-PMAGALLEY TIE ASSY
1510-1TIE ROD ASSEMBLY
1510-3TIE ROD ASSY
1510-5TIE ROD ASSY
1511-1TIE ROD ASSEMBLY
1532-1-TYTIE ROD
212A5629-11TIE ROD ASSY
212A5629-13TIE ROD ASSY
212A5629-15TIE ROD ASSY
212A5629-17TIE ROD ASSY
212A5629-19TIE ROD ASSY
212A5629-21TIE ROD ASSY
212A5629-23TIE ROD ASSY
212A5629-3TIE ROD ASSY
212A5629-5TIE ROD ASSY
212A5629-7TIE ROD ASSY
212A5629-9TIE ROD ASSY
213A1020-1TIE ROD ASSY
213A1020-3TIE ROD ASSY
213A1020-5TIE ROD ASSY
213A3430-1TIE ROD ASSY
287A4172-26TIE ROD ASSEMBLY
287A4172-27TIE ROD ASSEMBLY
30P511400000-501CONTROL ROD 7 ASSY TIE
344A6046-14TIE ROD ASSY
344A6046-6TIE ROD ASSY
344A6046-8TIE ROD ASSY
411A3270-1TIE ROD ASSY
411A3270-10TIE ROD ASSY
411A3270-11TIE ROD ASSY
411A3270-12TIE ROD ASSY
411A3270-13TIE ROD ASSY
411A3270-14TIE ROD ASSY
411A3270-15TIE ROD ASSY
411A3270-17TIE ROD ASSY
411A3270-18TIE ROD ASSY
411A3270-19TIE ROD ASSY
411A3270-2TIE ROD ASSY
411A3270-20TIE ROD ASSY
411A3270-3TIE ROD ASSY
411A3270-35TIE ROD ASSY
411A3270-4TIE ROD ASSY
411A3270-5TIE ROD ASSY
411A3270-55TIE ROD ASSY
411A3270-6TIE ROD ASSY
411A3270-7TIE ROD ASSY
411A3270-8TIE ROD ASSY
411A3270-9TIE ROD ASSY
411A3270-90TIE ROD ASSY
411U2618-59TIE ROD ASSY
411U2618-68TIE ROD ASSY
412T3008-6TIE ROD ASSY
412U2503-47TIE ROD ASSY
412U2503-48TIE ROD ASSY
412U2503-49TIE ROD ASSY
412U2503-51TIE ROD ASSY
412U2503-54TIE ROD ASSY
412U2503-60TIE ROD ASSY
412U2503-61TIE ROD ASSY
412U2503-72TIE ROD ASSY
412U2503-73TIE ROD ASSY
412U2503-76TIE ROD ASSY
412U2503-77TIE ROD ASSY
412U2503-78TIE ROD ASSY
412U2503-80TIE ROD ASSY
412U2503-81TIE ROD ASSY
412U2503-82TIE ROD ASSY
412U2503-93TIE ROD ASSY
412U2503-94TIE ROD ASSY
412U2504-1TIE ROD ASSY
412U2504-18TIE ROD ASSY
412U2504-5TIE ROD ASSY
413A3107-1TIE ROD ASSY
413A3107-2TIE ROD ASSY
413A3107-3TIE ROD ASSY
413A3107-4TIE ROD ASSEMBLY
413A3107-5TIE ROD ASSEMBLY
413A3107-8TIE ROD ASSY
413A3112-1TIE ROD ASSY
4391B1640-2TIE ROD ASSY
4391B1640-3TIE ROD ASSY
4391B1640-4TIE ROD ASSY
4391B1640-6TIE ROD ASSY
4605-505-AFROD ASSY, AIRFORCE
4609-607-AFROD ASSY, AIRFORCE
65-41334-13TIE ROD ASSY
65-49587-35TENSION TIE
657T4443-1TIE ROD ASSY
657T4443-2TIE ROD ASSY
65B12087-5TIE ROD ASSY
7401-4101TIE ROD ASSY
7402-4102TIE ROD ASSY
7403-4103TIE ROD ASSY
7405-4105TIE ROD ASSY
7406-4106TIE ROD ASSY
7407-4107TIE ROD ASSY
7408-4108TIE ROD ASSY
7409-4109TIE ROD ASSY
741-41306-13TIE ROD ASSY
7411-4111TIE ROD ASSY
7412-4112TIE ROD ASSY
7412-4113TIE ROD ASSY
7413-4113TIE ROD ASSY
7414-4114TIE ROD ASSY
7418-4118TIE ROD ASSY
7421-4121TIE ROD ASSY
7424-4124TIE ROD ASSY
7425-4125TIE ROD ASSY
777002-1TIE ROD ASSY
777002-2TIE ROD ASSY
777007-131TIE ROD ASSY
777081-178TIE ROD ASSY
777082-179TIE ROD ASSY
777083-180TIE ROD ASSY
777084-181TIE ROD ASSY
777085-182TIE ROD ASSY
777093-204TIE ROD ASSEMBLY
777178-612TIE ROD
777246-615TIE ROD ASSY
779-611015-2TIE ROD ASSEMBLY
9687-103TIE ROD ASSY
9753010-501TIE ROD ASSY
9753010-503TIE ROD ASSY
9753010-511TIE ROD ASSY
9753010-513TIE ROD ASSY
9753010-517TIE ROD ASSY
9761080-501TIE ROD ASSY
9761080-505TIE ROD ASSY
9761080-513TIE ROD ASSY
9761080-515TIE ROD ASSY
9761080-519TIE ROD ASSY
9761080-521TIE ROD ASSY
9761080-523TIE ROD ASSY
9761080-525TIE ROD ASSY
CA29370-001TIE ROD ASSY
OEM Project/Spares Enquiry

OEM Project/Spares Enquiry

CAPTCHA image

This helps us prevent spam, thank you.

Text Widget
Aliquam erat volutpat. Class aptent taciti sociosqu ad litora torquent per conubia nostra, per inceptos himenaeos. Integer sit amet lacinia turpis. Nunc euismod lacus sit amet purus euismod placerat? Integer gravida imperdiet tincidunt. Vivamus convallis dolor ultricies tellus consequat, in tempor tortor facilisis! Etiam et enim magna.
Cart
